High-Quality 12 volt golf cart batteries with BMS Manufacturer, Factory

1.BT Monitoring 2.Support Remote Diagnosis 3.Provide Smaller Size Solutions

Product Description

From the perspective of environmental protection, the pollution problem of lead-acid batteries is unavoidable. Lead plates and sulfuric acid solution of lead-acid batteries are difficult to degrade pollutants. The safety of lead-acid batteries and the impact of battery attenuation on the mileage are also headaches for the stadium. Take a two-seater golf cart as an example. The common golf carts on the market are equipped with six 175Ah lead-acid batteries. The cruising range of a new car equipped with this kind of battery is about 40Km after a full charge. However, as the usage time of the caddy increases, the battery's charging and discharging capacity will get worse, even less than 10km. The reduction of cruising range will greatly affect the normal use of the golf cart. These problems of lead-acid batteries cannot be solved from a technical point of view. However, the emergence of lithium batteries is a glimpse, and the use of lithium batteries to replace lead-acid power batteries has become an inevitable direction of development. The lithium battery technology is becoming more mature. In terms of technology and performance, the performance of the lithium battery version of the golf cart will be much better than that of the lead-acid vehicle. Looking back at the development of gasoline vehicles, facts have proved that the electrification of vehicles is an irreversible trend. Lithium electric golf carts are also a development trend. In the future, more and more lithium battery golf carts will serve the majority of golf courses.

Model No. ENGY-F12200N
Nominal voltage 12V
Nominal capacity 200Ah
Max. continuous charge current 150A
Max. continuous discharge current 150A
Cycle life ≥2000 times
Charge temperature 0°C~45°C
Discharge temperature -20°C~60°C
Storage temperature -20°C~45°C
Weight 27.2±0.5 kg
Dimension 521mm*233mm*222mm
Application For golf cart, power supply application, ect.
12V 200Ah LiFePO4 battery pack
Battery Specifications & Features
  • The ABS casing 12V 200Ah LiFePO4 battery pack for golf cart.
  • ABS casing with handles.
  • Standard charge current: 40A, 0.2C CC (constant current) charged to 14.6V, then CV (constant Voltage) 14.6V charge till current decline to 2600mA.
  • Max. charge current: 150A, 0.75C CC(constant current)charged to 14.6V, then CV(constant Voltage) 14.6V charge till current decline to 4000mA.
  • Standard discharge current: 40A, 0.2C, CC (constant current)discharged to 10V or cut off by BMS.
  • Max.continuous discharge current: 150A, It can be designed according to the clients' requirements.
  • Long cycle life: Rechargeable lithium ion battery cell, has more than 2000 cycles which is 7 times of the lead acid battery.
  • Superior safety: Almost the safest lithium battery type recognized in the industry.
YEARS OF LIFEPO4 BATTERY
LiFePO4 Battery Certificate 1 LiFePO4 Battery Certificate 2 LiFePO4 Battery Certificate 3 LiFePO4 Battery Certificate 4 LiFePO4 Battery Certificate 5 LiFePO4 Battery Certificate 6 LiFePO4 Battery Certificate 7 LiFePO4 Battery Certificate 8 LiFePO4 Battery Certificate 9 LiFePO4 Battery Certificate 10 LiFePO4 Battery Certificate 11 LiFePO4 Battery Certificate 12 LiFePO4 Battery Certificate 13 LiFePO4 Battery Certificate 14 LiFePO4 Battery Certificate 15 LiFePO4 Battery Certificate 16 LiFePO4 Battery Certificate 17 LiFePO4 Battery Certificate 18 LiFePO4 Battery Certificate 19 LiFePO4 Battery Certificate 20 LiFePO4 Battery Certificate 21 LiFePO4 Battery Certificate 22 LiFePO4 Battery Certificate 23 LiFePO4 Battery Certificate 24 LiFePO4 Battery Certificate 25 LiFePO4 Battery Certificate 26 LiFePO4 Battery Certificate 27 LiFePO4 Battery Certificate 28 LiFePO4 Battery Certificate 29 LiFePO4 Battery Certificate 30 LiFePO4 Battery Certificate 31 LiFePO4 Battery Certificate 32 LiFePO4 Battery Certificate 33 LiFePO4 Battery Certificate 34
LiFePO4 BATTERY

12 volt golf cart batteries enhance the performance, safety, and convenience of golf carts, making them an excellent choice for both recreational and commercial use.

Longer Lifespan
12 volt golf cart batteries generally have a much longer lifespan compared to traditional lead-acid batteries. They can last for up to 2,000 to 5,000 cycles, making them a cost-effective solution over time.
Lightweight
golf cart batteries 12 volt are significantly lighter than lead-acid batteries, which reduces the overall weight of the golf cart. This leads to improved efficiency and performance.
Faster Charging
These 12 volt golf cart battery can be charged much faster than their lead-acid counterparts. This minimizes downtime and allows for more time on the course.
Consistent Power Output
Golf cart 12 volt batteries provide a consistent voltage output throughout their discharge cycle. This means the golf cart maintains consistent performance until the battery is nearly depleted.
Low Maintenance
Unlike lead-acid batteries, Lifepo4 batteries require little to no maintenance. There's no need for regular watering or cleaning of corrosion.
Safety
Lifepo4 batteries have a very stable chemical composition, reducing the risk of overheating, catching fire, or exploding. They are designed with safety features to prevent overcharging and short circuits.
Environmentally Friendly
Lifepo4 batteries are more environmentally friendly as they do not contain toxic materials like lead or acid, and they are more easily recyclable.
High Efficiency
These batteries have a high energy efficiency, meaning less energy is lost during charging and discharging processes. This translates to more efficient use of energy and longer usage times.
Frequently Asked Questions
Are you a manufacturer?
Yes, we are a manufacturer based in China. Welcome to visit our facilities at any time.
Do you have current samples in stock?
Usually we do not, because different customers have different requests. Even if the voltage and capacity are the same, other parameters may be different. However, we can finish your sample quickly once the order is confirmed.
Are OEM & ODM available?
Sure, OEM & ODM are welcome, and the logo can be customized to suit your branding needs.
What's the delivery time for mass production?
Usually 15-25 days. It depends on the quantity, materials, battery cell model, and other custom requirements. We suggest checking the delivery time case by case.
What is your MOQ?
A 1PCS sample order is acceptable for testing purposes.
What is the normal lifetime of the battery?
More than 800 times for lithium ion batteries, and more than 2,000 times for LiFePO4 lithium batteries.
