Lithium iron phosphate batteries (LiFePO4 or LFP) offer lots of benefits compared to lead-acid batteries and other lithium batteries. Longer life span, no maintenance, extremely safe, lightweight, improved discharge and charge efficiency, just to name a few. LiFePO4 batteries are not the cheapest in the market, but due to a long life span and zero maintenance, it’s the best investment you can make over time.
Key Advantages of LiFePO4 Technology
🔋
Longer Lifespan
🛠️
Zero Maintenance
🛡️
Extremely Safe
⚖️
Lightweight Design
LiFePO4 batteries have become a leader in Lithium Iron Phosphate for power applications. These batteries are sturdy, with a lifespan measured over 6000 cycles at 80% DOD (depth of discharge). They are ideal for traction applications (EV, industry, etc.) and stationary batteries (Off Grid, Smart Grid, standalone applications, etc.).
Technical Specifications
| Model No. |
F100-29173202 |
| Nominal voltage |
3.2V |
| Nominal capacity |
100Ah |
| Max. continuous charge current |
1C |
| Max. continuous discharge current |
1C |
| Max. impulse discharge current |
2C |
| Cycle life |
≥2000 times |
| Charge temperature |
0°C ~ 45°C |
| Discharge temperature |
-20°C ~ 60°C |
| Storage temperature |
-20°C ~ 45°C |
| Weight |
2180g |
| Dimension |
28.82mm * 147.70mm * 202.47mm |
| Application |
Specially designed for UPS system, also can be used for Back-up power, telecommunication base station, solar/wind systems, home energy storage, etc. |
Key Applications
- EV, e-scooter, electric golf car, electric vacuum sweeper.
- Electronic toy, model airplane, remote control.
- Communication equipment: Cordless telephone, inter-phone.
- Modality equipment and consumer electronics.
- Decorative lighting, Solar lamps, torch, emergency light, solar street light and power supply.
Product Gallery
Frequently Asked Questions
What are the key benefits of LiFePO4 batteries compared to lead-acid?
LiFePO4 (Lithium Iron Phosphate) batteries offer a longer lifespan (over 6000 cycles at 80% DOD), require zero maintenance, are highly secure and lightweight, and deliver improved charge and discharge efficiency.
What is the lifespan and cycle capability of these cells?
These sturdy battery cells offer a lifespan measured over 6000 cycles at 80% Depth of Discharge (DOD), with a nominal cycle life of ≥2000 times under standard conditions.
What temperature ranges can this battery handle?
The battery is designed to charge within a temperature range of 0°C to 45°C. It can safely discharge between -20°C and 60°C, and be stored within a range of -20°C to 45°C.
What applications are best suited for these LiFePO4 batteries?
They are widely used in traction setups (EVs, e-scooters, electric golf cars), stationary systems (UPS, backup power, telecommunication base stations, solar/wind energy storage), and various consumer devices.
What are the exact dimensions and weight of this battery cell?
This specific cell weighs 2180g and has physical dimensions of 28.82mm * 147.70mm * 202.47mm.
