Rechargeable lithium batteries use safe lithium cell LiFePO4. Lithium-ion batteries are rechargeable lithium-ion batteries that can be used in tandem for more energy storage. Energy input are from wind energy or solar energy etc green energy, the electrical energy storage devices, can use different times to output electricity. For example, wind energy and solar energy are unstable and not easy to supply current all the time. Combined with wall-mounted battery packs, energy storage system problems will be solved. This battery is designed to achieve market leading energy density.
| Model No. |
LA-HEH48-20.0H-S1.0 |
| Battery |
20kWh |
| Battery Capacity |
400ah |
| Weight |
239kg |
| Dimension(L*D*H)mm |
710*450*1000 |
| Battery Type |
LiFePo4 |
| Rated Voltage |
51.2V |
| Working Voltage Range |
44.8~57.6 |
| Maximum Charging Current |
100ah |
| Maximum Discharging Current |
100ah |
| DOD |
80% |
| Communication |
RS485/CAN/WIFI |
| Charge temperature |
0°C~45°C |
| Discharge temperature |
-20°C~60°C |
| Storage temperature |
-20°C~45°C |
| Ingress Protection Rating |
IP20 |
| Certification |
UN38.3, MSDS, EN55032, EN55024, EN61000-3-2, EN61000-3-3 |
✓
Safe & reliable performance with Lithium Iron Phosphate (LFP) cell
✓
Flexible investment with 2.5kwh modular design, scalable from 5kwh to 20kwh
✓
80% depth of discharge (DoD)
✓
More usable energy with pack level energy optimization
Frequently Asked Questions
Are you a factory?
Yes, we are a professional manufacturer specializing in rechargeable lithium batteries. You are welcome to visit our facility at any time.
Do you have current samples in stock?
Usually we do not keep stock because different customers have different requests. Even if the voltage and capacity are the same, other parameters may differ. However, we can finish your sample quickly once the order is confirmed.
Are OEM & ODM services available?
Sure, OEM & ODM are welcome and logos can be customized to match your branding.
What is the delivery time for mass production?
Usually 15-25 days. It depends on the quantity, materials, battery cell models, and other factors. We suggest checking the delivery time case by case.
What is your MOQ?
A sample order of 1 PCS is acceptable for initial testing.
What is the typical lifetime of the battery?
More than 800 cycles for lithium-ion batteries, and more than 2,000 cycles for LiFePO4 lithium batteries.
